LED Flood Light
BZ-FL-A LED Flood Light
Aluminium-body flood light with toughened glass, Lumileds/Bridgelux SMD chips at 110-140lm/W and DONE, Meanwell or PHILIPS drivers; photocell, dimming and 10-20KV SPD optional.
Specifications
- Power
- 50W / 100W / 150W / 200W (BZ-FL-50WA to BZ-FL-200WA)
- Lumens
- 6500lm-26000lm, up to 130lm/W
- IP grade
- IP66
- Beam angle
- 60°/90°/120°
- Voltage
- 100-265V; AC/DC12V/24V/36V/48V/60V options
- Options
- Photocell (dusk to dawn), 0-10V/Triac/DALI, SPD 10-20KV
Sealed and Serviceable
IP66 aluminium housings behind toughened glass, with DONE, Meanwell or PHILIPS drivers and Lumileds/Bridgelux chips, carry a 3/5-year warranty.
Options that Matter Outdoors
Photocell for dusk-to-dawn running, 0-10V/Triac/DALI dimming for scene control, and 10-20KV surge protection for storm-exposed sites; DC12-60V inputs support solar-battery sites.
Where It Is Used
Yards, facades, sports courts and signage where a bracket-mounted IP66 flood with real driver options is specified.
Ordering Guidance
Send your project requirements - target lumen package, ceiling type, cut-out schedule or control protocol - through the contact form, and the ARTLITE team will confirm the exact model, options and quotation. OEM/ODM customization is available from 100 units.
