LED Panel Light
BZ-PL6060-MG Nano Grille Panel Light
LED panel with a nano high-reflective grille and TIR lenses that maximize luminous flux while keeping glare low (UGR<19). PC optical material resists heat, UV and yellowing.
Specifications
- Power
- 30W-96W
- Efficacy
- 140LM/W
- UGR
- <19
- CRI
- 80/90
- Dimension
- 595*595*20MM / 600*600*20MM / 603*603*20MM / 605*605*20MM
- CCT
- 3000K/4000K/6000K 3CCT in 1 lamp (DIP switch)
- Beam angle
- 90°
- Dimming
- 0-10V / Triac optional
Nano Grille Optics
The MG series combines a nano high-reflective grille with TIR optical lenses to capture stray light and put more of the luminous flux where it is needed, while keeping discomfort glare below UGR 19.
One Lamp, Three CCTs
A DIP switch selects 3000K, 4000K or 6000K inside the fitting, so one stocked SKU covers warm, neutral and cool office schemes. 0-10V and Triac dimming are available on request.
Where It Is Used
Widely installed in office areas, factories, buildings, schools, warehouses, conference rooms, exhibition halls and hospitals, in 595*595 through 605*605 ceiling grid sizes.
Ordering Guidance
Send your project requirements - target lumen package, ceiling type, cut-out schedule or control protocol - through the contact form, and the ARTLITE team will confirm the exact model, options and quotation. OEM/ODM customization is available from 100 units.
